Model 751 Panel Identification
ITEM DESCRIPTION PART NO.
1 PAN-DRIP 11-5/8 LONG 027503
2 PANEL-UPPER SIDE 024426
3 BUSHING-PANEL 013289
4 LOUVER-SIDE 017471
5 COVER A.-HOPPER-STD X38458-SER
6 GASKET-HOPPER COVER 038375
7 HOOD A. X35565
8 PANEL-REAR 013637
9 PANEL-UPPER SIDE R. 028823
10 PANEL A.-LOWER SIDE X24424
ITEM DESCRIPTION PART NO.
11 SCREW-1/4-20X3/8 RHM SS 011694
12 FASTENER-CLIP 1/4-20 045865
13 PANEL-SERVICE 047170
14 TRAY-DRIP 14-7/8L X 5-1/8 SG 013690
15 PANEL A.-SIDE-LOWER-LOUV. X39075
16 SHIELD-SPLASH 15"L 022763
17 DECAL-DEC-TAYLOR-SGL-SS 033230
18 PLATE-DEC 033239
*19 TRIM-REAR CORNER-RIGHT 020883
*20 TRIM-REAR CORNER-LEFT 020882
*NOT SHOWN
