Model 754 Panel Identification
ITEM DESCRIPTION PART NO.
1 PAN-DRIP 17-1/4"LONG 027504
2 PANEL-UPPER SIDE LEFT 028822
3 BUSHING-PANEL 013289
4 COVER A. - HOOPER -STD X38458-SER
5 GASKET-HOPPER COVER 038474
6 PANEL-REAR 017563
7 LOUVER-SIDE 017471
8 PANEL-UPPER SIDE RIGHT 028823
9 PANEL A.-SIDE LOWER RIGHT X46448
10 SCREW-1/4-20X3/8 RHM-SS 011694
ITEM DESCRIPTION PART NO.
11 FASTENER-CLIP 1/4-20 U-TYP 045865
12 PANEL-SERVICE 046584
13 TRAY-DRIP 22-7/8L X 5-1/8W 014533
14 SHIELD-SPLASH 23 LONG 022766
15 DECAL-DEC-TAYLOR-SS 032919
16 PLATE-DEC-754-755 032961
17 PANEL A.-SIDE LOWER LEFT X46447
18 HOOD 035434
*19 TRIM-REAR CORNER-RIGHT 013663
*20 TRIM-REAR CORNER-LEFT 013761
*NOT SHOWN
