Model 774 Exploded View
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X50327
1a BEARING-REAR SHELL 031324
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 COUPLING-DRIVE 3/4 HEX 012721
3 GEAR A. REDUCER4.21:1 021286
4 BOX-SPLICE N/A
4a BLOCK-TERMINAL 2P-L1,L2 039422
4b LUG-GROUNDING 020928
4c COVER-SPLICE BOX 042069
5 SCREW-5/16-18 X 3 HEX CAP 009497
6 PULLEY-2AK74-5/8 027822
7 BELT-AX34 025729
8 STUD-NOSE CONE 022822
9 CONE-NOSE N/A
10 SPACER-PROBE *SQ HOLE* 030966
11 PROBE A.-MIX 'SQUARE* X30922
12 MOTOR-1.5 HP 021522-
13 PULLEY-2AK22 X .625-.6265 016403
14 HINGE A.-MOTOR X25703
15 GUIDE A.-DRIP PAN X28699
16 BLOWER A. X47833-27
17 SHROUD-COND *AC*TOP 046576
18 SHROUD-COND *AC*REAR 046575
19 SHROUD-COND *AC*FRONT 046574
20 CONDENSER-AC-12LX18H 048233
21 VALVE-ACCESS 1/4FL X 1/4 044404
22 VALVE-EPR 1/4S 022665
23 DRYER-FILTER-HP62-3/8 048901
24 VALVE-EXP-AUTO-1/4 S X 1/4 046365
ITEM DESCRIPTION PART NO.
25 SWITCH-PRESSURE 440 PSI 048230
26 VALVE-ACCESS 1/4FL X 3/8 043232
27 VALVE-ACCESS 1/4FL X 1/4 047016
28 COMPRESSOR 048259-27
L63A113BBCA
29 SLEEVE-COMP. MOUNTING 037429
30 GROMMET-COMP. MT 037428
31 COMPRESSOR-TL3G-R134A 047701-
31a RELAY-START COMP. 047702-
32 CAPACITOR-START-60UF 047703
33 KIT COMPRESSOR MOUNT 047704
34 FRAME A. AC N/A
35 ADAPTOR A.-CASTER X18915
36 CASTER-SWV 5/8 STEM 018794
37 BOX A.-CAP&RELAY SEE PG. 80
38 CONTROL A. AC SEE PG. 72
39 COVER-CONTROL BOX 024440
40 DRYER-CAP TUBE 047699
41 CONDENSER-AC-7X6X1.25 027155
42 MOTOR-FAN 105CFM 027309-27
43 SHROUD-DANFOSS 027386
44 DISC-PROBE *SQ HOLE* 030965
45 SWITCH A.-DRAW X38547
46 BOARD-LOGIC-GEN 2.6-SD X36641SER1
47 BOLT-CARRIAGE 1/4-20 X 3/4 012347
48 PANEL A.-FRONT-SYRUP X42539
49 SWITCH-TOGGLE-4PDT 037394
50 CAP-RUBBER MOUNT 011844
51 BUSHING-MOUNTING 012258
52 CLAMP-MOUNTING 012257
53 SPRING-COMP.970x.115x2.0 025707
54 GROMMET-7/16X5/16 016212
