Model 794 Exploded View
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X51711
1a BEARING-REAR SHELL 031324
1b CONE-NOSE N/A
1c WASHER-BEARING LOCK 012864
1d NUT-BRASS BEARING 028991
1e GUIDE-DRIP SEAL 028992
2 COUPLING-DRIVE 3/4 HEX 012721
3 GEAR A*REDUCER 4.21:1 021286
4 SCREW-5/16-18 X 3 HEX CAP 009497
5 PULLEY-2AK74-5/8 027822
6 BELT-AX31 041575
7 PULLEY-2AK22 X.625-.6265 016403
8 HINGE A.-MOTOR-RIGHT X41836
9 CLAMP-MOUNTING 012257
10 BUSHING-MT RUBBER 012258
11 GROMMET-7/16X5-16 016212
12 SPRING-COMP.970x.115x2.0 025707
13 CAP-RUBBER MOUNT 011844
14 MOTOR-1.5 HP 021522-
15 STUD-NOSE CONE 022822
16 BOARD-LOGIC-GEN 2.6-SD X36641SER1
17 PROBE A.-MIX X30922
18 DISC-PROBE *SQ HOLE* 030965
19 SPACER-PROBE *SQ HOLE* 030966
20 VALVE-ACCESS 1/4FL X 1/4 044404
21 VALVE-EPR 1/4S 022665
22 COMPRESSOR-TL3G-R134A 047701-
22a RELAY-START COMP. 047702-27
23 CAPACITOR-START-60UF 047703
24 VALVE-ACCESS-1/4MFL X 1/4 047016
25 KIT-MOUNTING-COMP. 047704
ITEM DESCRIPTION PART NO.
26 FRAME A. N/A
27 SHROUD-DANFOSS 027386
28 MOTOR-FAN 105CFM 027309-27
29 CONDENSER-AC-7X6X1.25 027155
30 DRYER-CAP. TUBE 047699
31 BLOWER A. X47833-27
32 SHROUD-CONDENSER TOP 048245
33 DRYER-FILTER-HP62 048901
34 SHROUD-REAR 042693
35 VALVE-EXP-AUTO-1/4S 046365
36 CONDENSER-AC-12Lx18H 048233
37 SHROUD-FRONT 042692
38 COMPRESSOR 047519-
AHA2490ZXD-AH556E
39 GROMMET-COMP. MT 039923
40 SLEEVE-MOUNTING-COMP. 039924
41 SWITCH A.-DRAW X38547
42 SWITCH-TOGGLE^PDT 037394
43 HINGE A.-MOTOR-LEFT X41830
44 VALVE-ACCESS-1/4FL X 1/4 047016
45 SWITCH-PRESSURE 440PSI 048230
46 VALVE-ACCESS-1/4FL X 3/8 043232
47 ADAPTOR A.-CASTER X18915
48 CASTER-SWV 5/8 STEM 018794
49 CONTROL A. RIGHT SEE PG. 74
50 CONTROL A. LEFT SEEPG. 73
51 COVER-CONTROL BOX 048336
52 PANEL A.-FRONT X41820
53 BOLT-CARRIAGE 1/4-20 012347
*54 GUIDE A.-DRIP PAN X45691
*NOT SHOWN
