Taylor 8751 User Manual

Switch A.-Draw X43417-SER (Model 336)
ITEM DESCRIPTION PART NO.
1 SWITCH A.-DRAW X39269
1a SWITCH-LEVER-SPDT-11A 039252
1b SCREW-4-40 X1/2" TAPTITE 042604
1c BRACKET-DRAW SWITCH 039264
2 SCREW-8-32x3/8 HEX HEAD 039267
3 BRACKET A.-DRAW SWITCH X43418
4 PIN-PIVOT-DRAW SWITCH 038484
5 ARM-SWITCH-DRAW-RIGHT 038650
ITEM DESCRIPTION PART NO.
6 SPRING-RETURN-RIGHT 038924
7 BRACKET A.-SPRING RETURN X38257
8 SPRING-EXTENSION .375 X.045 038922
9 SPRING-RETURN-LEFT 038923
10 ARM-SWITCH-DRAW-LEFT 038649
11 E-RING 1/4 032190
12 ROD-SPRING RETAINER 043422
