Taylor 8751 User Manual

HP Refrigerant: 336 HP62, J5025164/up, 338 HP62, J7097467/up, 339 HP62 J5048332/up
DESCRIPTION PART 336 338 339 WARR. REMARKS PARTS
NUMBER QTY. QTY. QTY. CLASS UPDATE
ACCUMULATOR-COPPER 2"DIA 10" 047062 1 103
ADAPTOR A.-CASTER X18915 4 4 103
BEARING-FRONT 050216 2 2 2 000
BEARING-REAR SHELL *NICK.PLATE 031324 2 2 2 000
+GUIDE-DRIP SEAL 028992 2 2 2 000
+NUT-BRASS BEARING 028991 2 2 2 000
+WASHER-BEARING LOCK 012864 2 2 2 000
BEATER A.-2.8QT-HELICORE X35466 2 2 2 103
+BLADE-SCRAPER-PLASTIC 13-1/4L 035480 4 4 4 000
BELT-AX33 024396 4 000
BELT-AX35 022848 4 000 1 Ph 50/60 Hz
BELT-AX36 022849 2 000 3 Ph 50/60 Hz (LEFT BEATER MOTOR)
BELT-AX 34 025729 2 000
3 Ph 50/60 Hz (RIGHT BEATER
BELT-AX38 023873 4 000
BLOCK-TERMINAL 2P 039422 1 1 2 103 1 Ph
BLOCK-TERMINAL 3P 039423 1 1 2 103 3Ph
BLOCK-TERMINAL 5 POLE 024329 1 103
BLOWER A. X47833- 1 1 103
BOOT-CAPACITOR INSULATING 031314 1 1 000
CAPACITOR-RUN- 10 UF/370V 033047 1 1 103
HOUSING A.-W/WHEEL X30160-SER 1 1 103
MOTOR-BLOWER-208/230V 50/60 HZ 046536- 1 1 103
SCREEN-BLOWER *X30153* 030158 1 1 103
CLIP 030159 4 4 103
BOARD-LOGIC-GEN 2.6 W/SEL DIFF X36641SER1 2 2 2 212
BOARD-POWER-GEN 1 & 2 X32326-SER 2 2 2 212
FUSE-.063A-250V-5X20MM-SLO BLO 051272 2 2 2 103 114
BRUSH-DOUBLE ENDED-PUMP & FEED
013072 1 1 1 000
BRUSH-DRAW VALVE 1"ODX2"X17"L 013073 1 1 1 000
BRUSH-MIX PUMP BODY-3"X7"WHITE 023316 1 1 1 000
BRUSH-REAR BRG 1IN.DX2IN.LGX14 013071 1 1 1 000

Taylor 8751 Specifications

General

Brand	Taylor
Model	8751
Category	Ice Cream Maker
Language	English
