Taylor C152 - Parts Replacement Schedule; Parts Replacement and Maintenance Schedule

Section 9
9-1
085592-M
Parts Replacement Schedule
9
Parts Replacement Schedule
Maintenance Intervals
Table 9-1
Part Description Every 3 Months Every 6 Months Annually C152 Qty. C161 Qty.
Beater Drive Shaft Cup Seal X 1 2
Freezer Door O-Ring X 1 2
Freezer Door Front Bearing X 1 2
Freezer Door Guide Bearing X 1 2
Draw Valve O-Ring X 2 4
Center Draw Valve Seal X N/A 1
Pivot Pin O-Ring X 1 2
Black Bristle Brush, 1” x 2” Inspect and replace
if necessary.
Minimum 1 1
Double Ended Brush Inspect and replace
if necessary.
Minimum 1 1
White Bristle Brush, 1” x 2” Inspect and replace
if necessary.
Minimum 1 1
White Bristle Brush, 3” x 7” Inspect and replace
if necessary.
Minimum 1 1
Air Orifice O-Ring
X
Inspect and replace
if necessary.
Minimum 1 2
