22
Model C300Operating Procedures
090417
Step 15
Install the prime plug.
Figure 21
Step 16
Place the large o--ring into the door groove and
lightly lubricate.
Figure 22
Note: Every four months or less, discard the
o--rings and install new o--rings.
Step 17
Install the front bearing. Do not lubricate the front
bearing.
Figure 23
Step 18
Install the freezer door. Position the door on the four
studs on the front of the freezing cylinder. Firmly
push the door into place. Install the four handscrews
on the studs and finger--tighten them equally in a
criss--cross pattern to insure that the door is snug.
Do not over--tighten the handscrews.
Figure 24
Repeat these steps for the other freezing cylinder.
