Section 10 Parts List
36
Parts List Model C300
11101 1
+ Available Separately
DESCRIPTION PART
NUMBER
QTY. WARR.
CLASS
REMARKS
ACCUMULATOR-COPPER 2"DIA 13"LG 053377 1 103
ARM A.-IDLER SEE PULLEY-IDLER
BEARING-FRONT-SLUSH-PRESSURE 039349 2 000
BEARING A.-REAR SHELL *C303* X67222 000 S/N K409 & UP - REPLACES 032511/018432
+GUIDE-DRIP SEAL 028992 2 000
+NUT-BRASS BEARING 028991 2 000
+WASHER-BEARING LOCK 012864 2 000
BEARING-UNIT-REAR 1-3/8" SHAFT 054579 2 103
BEATER-PLASTIC-FCB-PRESSURIZED 041182 2 103
+BLADE-SCRAPER-F CB-16INCH 041103 4 000
BELT-1/2IN PITCH 240H100 033145 1 000 BEARING UNIT
BELT-POLY V-540J10 065639 1 000 REPLACES 054849
BLOCK-TERMINAL 2P-L1,L2 039422 1 103 208-230V 60HZ 1PH
BLOCK-TERMINAL-PLUG 6P .2 SIP 040322-002 1 103 208-230V 60HZ 1PH & 3PH
BLOCK-TERMINAL 3P L1,L2,L3 039423 1 103 208-230V 60HZ 3PH
BRUSH A.-PACKAGE C300 X64275 1 000
BRUSH-REAR BRG 1IN.DX2IN.LGX14 013071 1 000
BRUSH-DOUBLE ENDED-PUMP&FEED T 013072 1 000
BRUSH-DRAW VALVE 1-1/2"OD X 3" 014753 1 000
BRUSH-MIX PUMP BODY-3"X7"WHITE 023316 1 000
CABLE-RIBBON-14C-22"L-SIP/SIP 040040-019 1 103 TO LCD
CABLE-RIBBON-20C- 4"L-DIL/DILR 040040-057 1 103 J7UC TO J8IF
CABLE-RIBBON-20C-14"L-DIL/DILR 040040-056 1 103 J2UC TO J10IF
CABLE-RIBBON-50C- 3"L-DIL/DIL 040040-055 1 103 J10UC TO J9IF
CARD-CHECK OUT SLUSHTECH-5 YR 039976-W5 1 000
CLAMP-HOSE-SNAP IT-11/16-13/16 042610 2 000
CLIP-RETAINER *355* SYRUP LINE 053197 13 000 SS LINES
+O-RING-3/8 OD X .070W 016137 13 000 SS LINES
COMPRESSOR CS17K6E-PFV-238 052397-27E 1 512 208-230V 60HZ 1PH
+CAPACITOR-RUN- 35UF/440V 048132 1 103 "
