Taylor C300 User Manual

37
Model C300
Parts List
+ Available Separately
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
+CAPACITOR-START-189-227UF/250V 053106 1 103 " +RELAY-START-COMPRESSOR 051957-27 1 103 " +KIT-MOUNTING-COMPRESSOR CS 052197 1 000
COMPRESSOR CS18K6E-TF5-238 052397-33 1 512 200V 60HZ 3PH
+KIT-MOUNTING-COMPRESSOR CS 052197 1 000
CONDENSER-AC-16X16 3 ROW 14FPI 054660 1 103 CONTROL-SLUSH INTF W/NTB ROHS X64254-SER 2 212 S/N M1066646 & UP - REPLACES X45622-SER COUPLING A.-TORQUE-FCB-HEX X39523 2 103 COUPLING-TORQUE-DRIVE 046866 2 103 COUPLING-TORQUE-LOAD-HEX 039397 2 103 LABEL-IDENTIFICATION-RED 049285-RED 2 000 PIN-COUPLING-TORQUE 039453 6 103 SCREW-5/16-18X3/8 ALLEN SET 025376 4 000 SCREW-SHOULDER 3/16DX1/2L-SS 039455 6 000 SPRING-3/8 ODX3/16 IDX1L-RED 039734 6 103 DECAL-CONTROL *355* LEFT 052898 1 000 DECAL-CONTROL FCB-RIGHT 043636-R 1 000 DECAL-DEC-TAYLOR DOMED 053761 1 000 DECAL-INST-CLN-FCB-C300 055935 1 000 DECAL-TROUBLESHOOT 038374 1 000 DIAGRAM-WIRING *C300* W/CARB 059540-27 1 000 208-230V 60HZ 1PH DIAGRAM-WIRING *C300* W/CARB 059540-33 1 000 208-230V 60HZ 3PH DISPLAY-LED *C300* 10.5" 069143 103 S/N M1024026 & UP - NEW VENDOR - REPLACES 054683-27 DISPLAY-LIQUID CRYSTAL X38062-SER 1 103
+LENS-DISPLAY 038221 1 103 +STANDOFF-LENS 038225 4 000
DOOR-FREEZER-SLUSH-PRESSURE 039573 2 103
+CAP-SPOUT-DOOR-FCB-BLACK 046191-BLA 2 103 +HANDLE-DRAW-FCB-BLACK 046192-BLA 2 103 +NUT-SPOUT-DOOR-SLUSH-PRESSURE 039323 2 103 +O-RING-5-1/4O.D. X .210W 017003 2 000 DOOR GASKET
