Taylor C300 User Manual

38
Parts List Model C300
+ Available Separately
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
+PIN-PIVOT-SPOUT-DOOR-SLUSH 039321 2 103 +PLUG-PRIME-SLUSH-PRESSURE 039568 2 103 +O-RING-9/32 OD X 1/16 WALL 029751 4 000
SLIDE-HANDLE-DOOR-FCB-BLACK 046193-BLA 2 103
+SCREW-10-32X3/8PHL-TRUS HD-SS 053869 2 000
SPOUT-DOOR-FCB-BLACK 046190-BLA 2 103
+O-RING-1.129 ODX.989IDX.070W 039219 4 000
SPRING-COMP.480X.072X3.0-SS 039320 2 103 VALVE-DRAW-DOOR-SLUSH-PRESSURE 039324 2 103
+O-RING-9/16 OD X .103W 016369 4 000
ADAPTOR-MOUNTING-ADA-FCB 068579 2 103 ADA PARTS ADDED M103 & UP HANDLE-ADA-FCB 068580 2 103 ADA PIN-HANDLE-ADA-FCB 068601 2 103 ADA SCREW-10/32X1" PHIL TRUSS 069069 2 000 ADA
DRYER-FILTER 3/8 X 3/8SOL HP62 049154 1 000 DVD-OPS TRAIN VIDEO*C300/C302* 064416-DVD 1 000 FASTENER-DOOR LATCH 030787 1 000 POP UNIT SIDE FASTENER-DOOR STRIKE 030788 1 000 POP DISPLAY FILTER-AIR-15.88LX15.88HX.70W 052779-5 1 000 FILTER-CORCOM 6EH1 040140-001 1 103 FILTER-H20-5 MICRON-INLINE W 064422 1 000 S/N K7060000 & UP FLOW CONTROL-35PSI-W/O FLOAT S X53243S27H 2 103
BODY A.-FLOW CONTROL W/SOL. X48729-27S 2 103 BOWL A.-F LOAT-FLO CNTRL-W/PLUG X53244 2 103 SCREW-8-32X3/8TAPTITE-HEX HD 041951 4 000 SWITCH-PRESSURE-SYRUP-35PSI CO 048784 2 103
FLOWMETER A.-INJECTION-C02 X55785 1 103 K109 THRU K408 FUSE-BUSS-ABC-15-R ROHS C 076414 000 S/N M1042255 & UP REPLACES 45293 GASKET-BASE PAN *300* 054666 1 000 GASKET-FRONT PANEL 049031 2 000 GUARD-FAN 500304 1 103
