Taylor C300 User Manual

39
Model C300
Parts List
+ Available Separately
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
GUIDE A.-DRIP PAN *C300* X54686 1 103 HARNESS-WIRE-C300 PWR/COMP 056334-27 1 103 HARNESS-WIRE-C300-L0 VOLT 055503 1 103 208-230V 60HZ 1PH & 3PH HARNESS-WIRE*C300*HI VOLT-CARB 059537-27 1 103 208-230V 60HZ 1PH & 3PH HARNESS-WIRE *C300* PWR/COMP 056334-33 1 103 208-230V 60HZ 3PH HINGE-DISPLAY-P.O.P.-LIGHT 059584-6 HOLDER-FUSE-INLINE-TYPE H 064538 103 S/N M1042255 & UP REPLACES 045606 HOOD *C300* 054677 1 103 KIT A.-TUNE UP X39699 2 000
BEARING-FRONT-SLUSH-PRESSURE 039349 2 000 O-RING-1.129 ODX.989IDX.070W 039219 4 000 O-RING-3.437 ID X .275 W 016037 2 000 O-RING-5-1/4O.D. X .210W 017003 2 000 O-RING-7/8 OD X .139W 025307 2 000 USED WITH 032511 RSB NO LONGER USED W/X67222 O-RING-9/16 OD X .103W 016369 4 000 O-RING-9/32 OD X 1/16 WALL 029751 4 000 SEAL-DRIVE SHAFT 032560 2 000 TOOL-O-RING REMOVAL-FREEZER 048260-WHT 2 000
LABEL-DOOR-MOVE PART 032749 1 000 LABEL-SWITCH-CONTROL 053145 1 000 LABEL-WARN-COVER 051433 4 000 LABEL-WARN-NO DRAW 042279 2 000 LABEL-WARN-RELIEVE PRESS 039462 2 000 LED A.-PRODUCT NOT READY 059711 1 103 REPLACES 051807 LENS-YEL LED-SNAP IN 1/4" HOLE 051751 2 103 LINE A.-CO2 *C300* SOL/PUMP-NP X56839-1 1 LINE A.-CO2-MAN/SOL. *C300* X59538 1 LINE A.-CO2-MAN/CARB *C300* X62513 1 LINE A.-CO2-SUPPLY-SS *C300* 059536 1 103 LINE A.-DRAIN *C300* REAR X55783 1 103
FITTING-Y 1/2 BARB PLASTIC 057376 1 103 REPLACES 055744
