Taylor C300 User Manual

40
Parts List Model C300
+ Available Separately
DESCRIPTION REMARKSWARR.
CLASS
QTY.PART
NUMBER
TEE-1/2ID X 1/2ID BARB PE 600001 1 103
TUBE-VINYL 1/2ID X 11/16 OD 020944-10 1 000 R30335 TUBE-VINYL 1/2ID X 11/16 OD 020944-16 3 000 R30335 TUBE-VINYL 1/2ID X 11/16 OD 020944-23 1 000 R30335
LINE A.-LIQUID *C300* W/CARB. X59542-27 1 NNN
ELBOW-3/8S-STREET-SHORT RADIUS 013017 1 000 TEE-3/8S-COPPER 002403 1 000 VALVE-SOL-7/64 ORFX3/8SI-1/4 062087-27 2 103
LINE-MIX *C300* LEFT-SS 056613 1 103 LINE-MIX *C300* RIGHT-SS 056614 1 103 LINE A.-MIX *C300* C02-LEFT-SS X55751 1 103
LINE A.-MIX *C300* C02-LEFT-SS X55753 1 103 O-RING-3/8 OD X .070W 016137 2 000 ADAPTOR-SWV 1/4F 1/4BARB*SS* 016715 1 103 TUBE-NYLOBRADE 1/4ID X 7/16OD 020568-6 1 000 R30317 FERRULE-.475 ID NP BRASS 021082 1 000 CLAMP-HOSE-1/2-STEPLESS EAR 053960 1 000
LINE A.-MIX *C300* CO2-RIGHTSS X55752 1 103
LINE A.-MIX *C300* C02-RIGHTSS X55755 1 103 O-RING-3/8 OD X .070W 016137 2 000 ADAPTOR-SWV 1/4F 1/4BARB*SS* 016715 1 103 TUBE-NYLOBRADE 1/4ID X 7/16OD 020568-6 1 000 R30317 FERRULE-.475 ID NP BRASS 021082 1 000 CLAMP-HOSE-1/2-STEPLESS EAR 053960 1 000
LINE A.-SYRUP *C300* SS-LEFT X55765 1 103 LINE A.-SYRUP *C300* SS-RIGHT X55768 1 103 LINE A.-WATER *C300* INLET X64393 1 103 S/N K6048746 & UP - U/D 190
ARMAFLEX 5/8 ID X 3/8WALL 032650-10 1 NNN CLAMP-HOSE 23/32-STEPLESS EAR 053957 3 NNN FERRULE-.650 ID NP BRASS 029834 2 000 FITTING-3/8MFLX3/8BARB BULKH 052806 1 103
