Taylor C716 User Manual

9
Models C708 & C716 Operator Parts Identification
110506
Model C708 Explod ed View Parts Identification
ITEM DESCRIPTION PART NO.
1 PANEL-SIDE-LEFT 056963
2 PAN-DRIP 11-5/8 LONG 027503
3 PIN-RETAINING-HOPPER CVR 043934
4 KIT A.-COVER-HOPPER X65368
5 BLADE A.-AGITATOR X56591
6 PUMP A.-MIX SIMPLIFIED S.S. X57029-14
7 PANEL-REAR 056077
8 PAN A.-DRIP 5 1/2” LONG X56074
9 SCREW-1/4-20X3/8 RHM-STNLS 011694
10 PANEL A-SIDE-RIGHT X57871
ITEM DESCRIPTION PART NO.
11 PANEL A.-FRONT-UPPER X59423
12 COVER-ACCESS-FRONT R. 056933
13 STUD-NOSE CONE 055987
14 SCREW10X3/8SLOTTED 015582
15 COVER-ACCESS-LEFT 056946
16 FILTER-AIR 052779-9
17 PANEL A.-FRONT-LOWER X58955
18 SHELF-TRAY-DRIP 056076
19 TRAY-DRIP 056858
20 SHIELD-SPLASH 049203

Taylor C716 Specifications

General

Hopper Capacity	20 quarts (18.9 liters)
Separate Hopper Refrigeration (SHR)	Yes
Air Cooled	Yes
Freezing Cylinder	One
Mix Hopper	One
Electrical	208-230/60/1
Motor	1.5 HP
Indicator Lights	Mix Low
Refrigeration System	Air Cooled
