Models C708 & C716Important: To the Operator
150413
System Information
The SYSTEM INFORMATION is displayed on four
separate screens. The first screen contains the
control and software version installed in the
machine.
SOFTWARE VERSION
C708 CONTROL UVC4
VERSION X.XX
> Next
Touch the SEL key to advance to the next system
information screen containing the software language
version.
Language
V5.01 English
> Next
Touch the SEL key to advance to the next screen.
Bootloader
V1.13.000
> Next
Touch the SEL key to advance to the system
information screen containing the model bill of
material and machine serial number. Touching the
SEL key again will return to the Menu list.
B.O.M. C700000000
S/N M0000000
Othr= 00000
> Next
Current Conditions
The CURRENT CONDITIONS screen provides the
viscosity readings for the product when the machine
is running, and the hopper and the freezing cylinder
temperatures for the machine.
VISC 0.0
HOPPER 41.0
BARREL 41.0
CURRENT CONDITIONS is the only Menu screen
that will return the control panel keys to normal
operation. The Menu keys will not be lit when this
option is selected but the panel touch keys are fully
functional. Exit the CURRENT CONDITIONS screen
and return to the Menu by touching the SEL key.

Taylor C716 Specifications

General

Hopper Capacity	20 quarts (18.9 liters)
Separate Hopper Refrigeration (SHR)	Yes
Air Cooled	Yes
Freezing Cylinder	One
Mix Hopper	One
Electrical	208-230/60/1
Motor	1.5 HP
Indicator Lights	Mix Low
Refrigeration System	Air Cooled
