TBS CROSSFIRE Micro TX - Telemetry Data Points Overview



Telemetry
The following table provides an overview of the telemetry points available for the TBS compatible
equipment. Note that Pixhawk APM and EagleTree telemetry is not included here.
Datapoint
Description
Data source
1RSS
Uplink - received signal strength antenna 1 (RSSI)
TBS CROSSFIRE RX
2RSS
Uplink - received signal strength antenna 2 (RSSI)
TBS CROSSFIRE RX
RQly
Uplink - link quality (valid packets)
TBS CROSSFIRE RX
RSNR
Uplink - signal-to-noise ratio
TBS CROSSFIRE RX
RFMD
Uplink - update rate, 0 = 4Hz, 1 = 50Hz, 2 = 150Hz
TBS CROSSFIRE RX
TPWR
Uplink - transmitting power
TBS CROSSFIRE TX
TRSS
Downlink - signal strength antenna (radio controller)
TBS CROSSFIRE TX
TQly
Downlink - link quality (valid packets)
TBS CROSSFIRE TX
TSNR
Downlink - signal-to-noise ratio
TBS CROSSFIRE TX
GPS
GPS Coordinates
TBS GPS/Compass/ BF
Alt
GPS Altitudes
TBS GPS/Compass/ BF
Sats
GPS Satellites acquired
TBS GPS/Compass / BF
!!!!!!
Magnetic orientation
TBS GPS/Compass/ BF
RxBt
Battery voltage
TBS CORE PRO / FPVision/ BF
Curr
Current draw
TBS CORE PRO / FPVision/ BF
Capa
Current consumption
TBS CORE PRO / FPVision/ BF
Ptch
FC Pitch angle
BetaFlight FC with CRSF
Roll
FC Roll angle
BetaFlight FC with CRSF
Yaw
FC Yaw angle
BetaFlight FC with CRSF
FM
Flight mode
BetaFlight FC with CRSF






