INSTRUCTION MANUAL
HWS 3000G
TDK-Lambda
<Page>
10/49
CN71 are isolated from the power input and output circuits.
2-1-3. CN71
*CN71 Connector（JST）
CN71
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
TOPTOP
Housing Terminal Pin
PHDR-10VS
SPHD-002T-P0.5 (AWG24 ~ 28) or
SPHD-001T-P0.5 (AWG22 ~ 26)
Connector
S10B-PHDSS
Use SPHD-001T-P0.5 (AWG22 ~ 26) for the AUX and GND terminals, and select a wire with a
thickness according to the output current.
Use maker recommended crimping tool.
Hand Crimping Tool ：YRS-620(SPHD-002T-P0.5)(JST) or YC-610R(SPHD-001T-P0.5)(JST)
Configuration No. Pin name Function
1 AUX
+ output terminal of auxiliary power output
2 AUX
+ output terminal of auxiliary power output
3 GND
- output terminal of auxiliary power output
(internally connected to DG terminal.)
4 GND
- output terminal of auxiliary power output
(internally connected to DG terminal.)
5 DG
Ground for L/E,ACF,CPF,VPF
(internally connected to GND terminal.)
6 L/E
Leader machine setting terminal for Leader/Follower operation, short-circuiting
with DG terminal sets Leader machine setting.
7 DG
Ground for L/E,ACF,CPF,VPF
(internally connected to GND terminal.)
8 ACF
Input voltage shortage alarm
（Open collector output. Opens when input voltage is lost.)
9 CPF
Constant current output mode current shortage alarm
(Open collector output. Open when output current decreases)
10 VPF
Constant voltage output mode voltage shortage alarm
(Open collector output. Open when the output voltage drops)
