TDK-Lambda HWS 3000G - Page 9

INSTRUCTION MANUAL
HWS 3000G
TDK-Lambda
<Page>
9/49
*CN41、CN42 Connector（JST）
Use maker recommended crimping tool.
Hand Crimping Tool ：YRS-620(SPHD-002T-P0.5)(JST) or YC-610R(SPHD-001T-P0.5)(JST)
These are connected by short pieces at time of shipment.
CN41 : -R terminal (Pin No.9) to AG terminal (PinNo.12)
Connector for remote sensing.
CN61 is connected to the output of the power supply.
Note: Products with 60 V output and products with 130 V output will have voltages above 60 V.
*CN61 Connector（JST）
CN61
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
TOPTOP
Housing Terminal Pin
PHDR-16VS
SPHD-002T-P0.5 (AWG24 ~ 28) or
SPHD-001T-P0.5 (AWG22 ~ 26)
Connector
S16B-PHDSS
2-1-2. CN61
Housing Terminal Pin
PHDR-8VS
SPHD-002T-P0.5 (AWG24 ~ 28) or
SPHD-001T-P0.5 (AWG22 ~ 26)
Connector
S8B-PHDSS
Use maker recommended crimping tool.
Hand Crimping Tool ：YRS-620(SPHD-002T-P0.5)(JST) or YC-610R(SPHD-001T-P0.5)(JST)
These are connected by short pieces at time of shipment.
-S terminal (Pin No.1）to -L terminal (Pin No.2）
+S terminal (Pin No.7）to +L terminal (Pin No.8）
*The attached short piece is designed for basic insulation between CN61 and FG.
Configuration No. Pin name Function
1 -S
Remote sensing terminal for -output side.
(For remote sensing function, which compensates for line drop between
power supply terminals and load terminals. Connect to -L terminal when
remote sensing function unnecessary.)
2 -L
Local sensing terminal, internally connected to -output terminal.
( -L terminal cannot supply load current.)
3 NC
Do not connect.
4 NC
Do not connect.
5 NC
Do not connect.
6 NC
Do not connect.
7 +S
Remote sensing terminal for +output side.
(For remote sensing function, which compensates for line drop between
power supply terminals and load terminals. Connect to +L terminal when
remote sensing function unnecessary.)
8 +L
Local sensing terminal, internally connected to +output terminal.
( +L terminal cannot supply load current.)
