4-2. Signal wiring
(1) Be sure to twist the signal wire and separate it from the input and output wires.
(2) Hold the socket housing firmly and insert it straight into the post until it clicks into place.
(3) To pull out the connector, hold the wires together, secure the socket housing with your fingers
so as not to pry it, and pull it out while mating.
