2.12. EMC
2.12.1. 208 Volts Input Models
CE Mark
1. ESD --- EN61000-4-2 (IEC 801-2) Air-disch. */-8kV, contact disch. +/-4kV
2. Fast transients --- EN61000-4-4 (IEC 1000-4-3)
3. Surge immunity --- EN61000-4-5 (IEC 1000-4-5)
4. Conducted immunity --- EN61000-4-6 (IEC 1000-4-6)
5. Radiated immunity --- EN61000-4-3 (IEC 1000-4-3)
6. Power Frequency Magnetic Field --- EN61000-4-8
7. Conducted emission --- EN55011A, FCC part 15J-A
8. Radiated emission --- EN55011A, FCC part 15J-A
2.12.2. 400 Volts Input Models
CE Mark
1. ESD --- EN61000-4-2 (IEC 801-2) Air-disch. +/-8kV, contact disch. +/-4kV
2. Fast transients --- EN61000-4-4 (IEC 1000-4-3)
3. Surge immunity --- EN61000-4-5 (IEC 1000-4-5)
4. Conducted immunity --- EN61000-4-6 (IEC 1000-4-6)
5. Radiated immunity --- EN61000-4-3 (IEC 1000-4-3)
6. Power Frequency Magnetic Field --- EN61000-4-8
7. Voltage Dips, Short Interruptions and
Voltage Variations Immunity Tests
(400VAC Input Only)
--- IEC 61000-4-11
8. Conducted emission --- EN55011A, FCC part 15J-A
9. Radiated emission --- EN55011A, FCC part 15J-A
2.13. RELIABILITY SPECS
1. Electrolytic capacitors life Yrs. More than 3yrs at 40C ambient, 100% load
2. Grade --- G-2, Lambda Group derating criteria & EIAJ RCR-9102A
count Reliability, Generic Failure rates, 25C
4. Warranty Yrs. 5 years
5. Shelf life Yrs. 5 years, electrolytic caps shall be reformed after 2 years
2.14. SAFETY
1. Applicable Standards --- UL/ULC 60950-1, EN60950-1 recognized. All Outputs are Hazardous. (Units with IEMD or ISOL option are
Recognized up to 400 volts output). CE Mark 208 & 400VAC input only (CB Scheme)
Vout≤40V: Output is SELV, IEEE/Isolated analog are SELV.
40<Vout≤400V: Output is hazardous, IEEE/Isolated analog are SELV.
400<Vout≤600V: Output is hazardous, IEEE/Isolated analog are not SELV.
2. Withstand voltage --- Vout=<60V models: Input-Ground: 2818VDC 1 min, Input-Outputs (SELV): 4242VDC 1 min, Output –
Ground: 1000VDC 1 min. 60<Vout=<300V models: Input-Ground: 2828VDC 1 min, Input-Haz. Output:
3535VDC 1 min, Input-SELV: 2828VDC 1 min. Hazardous Output-SELV: 2121VDC 1 min, Hazardous
Output-Ground: 2121VDC 1 min. 300<Vout=<600V models: Input-Ground: 2828VDC 1 min, Input-Haz.
Output: 3535 1 min, Input-SELV: 2828VDC 1 min. Hazardous Output-SELV: 2688VDC 1 min, Hazardous
Output-Ground: 2688VDC 1 min.
3. Insulation resistance --- 100Mohm at 500Vdc
