29
83-530-000 Rev J
2.15. J1 CONNECTOR
J1-1 ENA_IN Enable/Disable Dry Contact with J1-14
J1-2 IF_COM Isolated Interface Common. Return for SO, PS_OK
J1-3 IF_COM Isolated Interface Common. Return for SO, PS_OK
J1-4 N/C
J1-5 N/C
J1-6 N/C
J1-7 N/C
J1-8 LOC/REM Input for selecting between Local or Remote analog programming.
J1-9 VPGM Input for remote analog voltage/resistance programming of the Output Voltage
J1-10 IPGM Input for remote analog voltage/resistance programming of the Output Current
J1-11 VMON Output Voltage Monitor
J1-12 COM Control Common for VMON & IMON
J1-13 CV/CC Output for Constant Voltage / Constant Current mode indication
J1-14 ENA_OUT Enable/Disable Dry Contact with J1-1
J1-15 SO Input for Shut-Off control of the output.
J1-16 PS_OK Output for indication of the power supply status
J1-17 N/C
J1-18 N/C
J1-19 N/C
J1-20 N/C
J1-21 LOC/REM Signal Output for indicating if the unit is in Local or Remote analog programming mode.
J1-22 VPGM_RTN Return for VPGM J1-9; connected to Neg Output
J1-23 IPGM_RTN Return for IPGM J1-10; connected to Neg Output
J1-24 IMON Output for Current Monitor
J1-25 P Output for Current Balance in Parallel Operation (One wire – Reference to
Negative Output)
