TEC EM1-31064 - 8 Level Adjustment

8-1
8. LEVEL ADJUSTMENT
8. LEVEL ADJUSTMENT
1. Level Gauge
Set the scale on a stable and level surface. Level the scale by turning the adjustable legs so
that the air bubble is inside the center circle.
EM1-31064
8. LEVEL ADJUSTMENT
2. Adjustment Procedure
1 When the air bubble moves toward the left side, turn the right adjustable legs clockwise.
2 When the air bubble moves toward rear, turn the front adjustable legs clockwise.
Correct
Incorrect
