11. PROGRAMMING PROCEDURES
EM1-31064
11.18 TRANSFERRING LOGO DATA
Table 6: Error message for data transmission
Error message
Cause
Error position
Header text Data text
DATA ERROR
Timeout
Incorrect segment
Incorrect logo size
Incorrect number of logos
Incorrect logo number
Incorrect number of dots to be printed.
Parity error
Framing error
Overrun error
Print LOGO
(256 x 64 dots)
<Display>
<Label Print>
: LOGO data
: Print/Display area
<Receipt Print>
1st LOGO
(LOGO is printed
on the center of
printing area.)
2nd LOGO
(Part of LOGO
is printed)
160
64
FSP LOGO
(LOGO is printed
on part of FSP
print area)
SL-9000N only
(LOGO #1 & half of
LOGO #2 are printed.)
