Technalogix TP1000 - DVB-S;S2 Module Configuration

33
Introduction to the parameters of status:
Parameters
Description
Total Rate
Indicates the total bit rate of input signal, including the valid and null
packet. The unit is Mbps
Effective Rate
Indicates the bit rate of valid packet (excluding the null packet). The unit
is Mbps.
C/N
Indicates the real-time carrier to noise ratio.
BER
Indicates the real-time bit error rate.
3.1.4.3 DVB-S/S2 Module
 Setting
Pic-3.1-25
