Technaxx TX-29

4
TX-29
TX-30
No.
Name
Function
1
AUTO key
Adjusts the screen display automatically.
2
MENU key
Activates and exits the OSD menu settings of the display (monitor)
3
← key
Moves the OSD menu or decreases the selected item value or
decrease volume of the display (monitor).
4
→ key
Moves the OSD menu or increases the selected item value or
increase volume of the display (monitor).
5
Screen key
Turn on/turn off the display screen.(monitor)
6
LED
Indicator
The power LED lights up green when the display screen is turned on.
The power LED lights up red when the display screen is turned off.
7
HDMI
connector
HDMI output signal can be connected to another HD monitor for
displaying.
8
Net
For a wired connection, connect this to a spare port on your home
router (without this connection no access over the internet).
9
USB Ports
USB 2.0 Ports for mouse & external device(USB disk)
10
Power
socket
Connect the power adapter here.(DC12V/2A or DC12V/3A)
11
Power
On/Off
Turns ON/Off the monitor (only TX-30)
