15
Network setup:
DHCP will be set as default it is the easiest way that the TX-29/TX-30 connects with your
network and get an IP. But it is also possible to set the IP address manually. The IP address
and the port (default 81) of your device are shown on this page. The page displays the
network status where you can see if the device is connected to a network and the internet.
(Healthy network = OK; Network cable Disconnected = fails to connect.)
Device ID has to be checked to get a connection when you are not at home. The number
(Device ID) is needed to login on www.technaxxp2p.de to access the TX-29/TX-30 from
everywhere.
Note: The precondition to generate Device ID is that make sure the NVR is connected with
internet, and IP address is available.
After successful connection to your network and internet the NVR will get an IP address
and generates Device ID automatically, once generated, it will appear in menu.
You find the QR Code of the device for easy setup when you click on “Show QR Code”.
Enable the DDNS Function and set the data to use the service.
(Notice to use www.technaxxp2p.de which is enabled and useable from
factory.)
Select enable and input “Username” and “Password” you get from your
ISP (Internet service provider).
Click Apply, you need to restart to activate your configuration.
After rebooting, TX-29/TX-30 will connect to internet automatically. The IP
in the PPPoE is the dynamic value. You can access this IP to visit the unit.
