3. Device Installation
Important Note:
Before the installation, make sure the installation environments can at least support 3x
weight of the camera and the bracket.
3.1 Installation TX-65
Figure 3-1
See Figure 3-1 and Figure 3-2.
Step 1: Stick installation sticker to designated surface where you will install the device (wall
or ceiling).
Step 2: Dig a hole according to position of hole on installation sticker.
Step 3: Open accessories bag, take out expansion bolt and insert it into the hole you just
dug.
Step 4: Open accessories bag, take out screw. Tighten the 4 screws to fix the device on
the installation surface (wall or ceiling). Move device sunshade back and forth. When you
have fixed the device, you must tighten screws on sunshade.
Step 5: Plug external wiring of the device properly.
