Technaxx TX-67 - Installing the TX-66 Camera

12
Figure 3-2
Step 6: Use Philip’s head screwdriver (in accessories bag) to loosen Locking screw.
Step 7: Adjust the device in all possible directions, and set its monitoring direction.
Step 8: Use Philip’s head screwdriver to tighten the screws.
3.2 Installation TX-66
Figure 3-3
Ceiling or Wall
Expansion Bolt
Dome Body
Installation Screw
Dome Enclosure
Enclosure Fixed Screw
Locking Screw
