RQT7231
13
Fader start function
You can start music play from the SL-DZ1200 direct drive digital turntable (not included) using the channel fader and cross fader by connecting the
digital turntables to CH1 and CH4. (A control cable is necessary for this connection.
page 8)
3 Switch [FADER START (CH1)] to ON
1 Turn [ASSIGN A] and select any number
other than 1
•The channel fader will not start the digital turntable if 1 is
selected.
2 Push the channel fader all the way to
zero
4 Push the channel fader up when you
want to start play
•Play instantly begins from the digital turntable.
Start using the channel fader
If you push the channel fader back to the original position (zero) after
play on the digital turntable has started, the digital turntable returns to
the set point and waits in the standby position.
3 Switch [FADER START (CH1)] to ON
1 Turn [ASSIGN A] and select 1
2 Push [CROSS FADER] all the way in the
direction opposite the source you want
to start ( )
Start using the cross fader
If you push the cross fader back to the original position after play on
the digital turntable has started, the digital turntable returns to the set
point and waits in the standby position.
4 Slide [CROSS FADER] in the direction
opposite of instruction 2 when you want
to start play
•Play instantly begins from the digital turntable.
Alternate play of two digital turntables connected to CH1
and CH4
When the cross fader operation switch is set to NORMAL.
3 Switch [FADER START (CH1)] and
[FADER START (CH4)] to ON
1 Turn [ASSIGN A] to select 1 and turn
[ASSIGN B] to select 4
4 Push [CROSS FADER] all the way in the
direction opposite of instruction 2
(towards ), when you want to start
play
•Play instantly begins from the digital turntable connected to
CH1. (At the same time, the digital turntable returns to the
set point when playing on CH4)
5 Push [CROSS FADER] all the way in the
direction opposite of instruction 4
(towards )
•Play instantly begins from digital turntable on CH4.
•Play on CH1 instantly returns to the set point.
When the digital turntable you want to control is connected to CH1
and the channel fader operation switch is set to NORMAL.
•When individually adjusting the left (L) and right (R) input ( page
12), perform the following instructions simultaneously for the CH1
and CH2 channel faders on the panel.
When the digital turntable you want to control is connected to CH1
and the cross fader operation switch is set to NORMAL.
Before use
•Turn [MODE] to TURNTABLE on the rear panel of the digital
turntables connected to CH1 and CH4.
•Set the auto cue point and cue point on the digital turntables
connected to CH1 and CH4, and standby at the set point.
Note
While you are using the fader to start play, turning the unit off and on
may stop or start the digital turntable.
2 Push [CROSS FADER] all the way in the
direction opposite the source you want
to start ( )
To Next Page
