Techno CNC Systems NK105G2 - Page 30

30
Call: 1-631-648-7481 or Visit: support.technocnc.com
HD Series Manual
NK105G2
10
2. Current Tool No
1
3. Tool Offset
1. Tool 1
X: _____
Y: _____
Z: _____ (settings repeat through tool 10)
15. ENG Unit
YES
5. MFR Param PASSWORD: 33587550
1. Velocity 
1. Decel Dist
0.394 inch
2. Approach Speed
25.00 in/min
3. Single Axis Acc
25.00 in/sec^2
4. Max Turn Acc
100.00 in/sec^2
5. Jerk
300.00 in/sec^3
6. Max Speed of Z
125.00 in/min
7. Short Seg Spd Lmt
YES
8. SPDLMT Length
0.1 inch
9. Enbl Plunge Rate
NO
10. Z Plunge Cut Spd
50.00 in/min
11. REF Circle Radius
0.1 inch
12. REF Circle Speed
100.00 in/min
2. Axis Output Dir *
X: Negative
Y: Negative
Z: Negative
3. Pulse Equiv *
X: 0.007855 0.0062100 (Mini) 0.0012500 (BT1212)
Y: 0.007855 0.0062100 (Mini) 0.0012500 (BT1212)
Z: 0.002500 0.0031720 (Mini) 0.0012500 (BT1212)
Settings (continued)
X: 0.0078125 (HD Series) 0.005000 (HD Mini)
Y: 0.0078125 (HD Series) 0.005000 (HD Mini)
Z: 0.0025000 (HD Series) 0.002500 (HD Mini)
