HD Series Manual
NK105G2
4. Machine Stroke 
1. Strk Upper Lmt 
X:
Y: varies depending on machine size
Z:
2. Strk Lower Lmt 
X:
Y: varies depending on machine size
Z:
5. Ref Point Set 
1. RefP Speed 
X: 70 in/min
Y: 70 in/min
Z: 60 in/min
2. RefPDir
X: Negative
Y: Negative
Z: Positive
3. Retract Dist
1. X Retract Dist
0.079 inch
2. Y Retract Dist
0.079 inch
3. Z Retract Dist
0.079 inch
6. Spindle Set 
1. Spindle Gears*
7
2. On/Off Delay
5000 ms
3. Initial Gear*
6
4. Max Spdl Speed*
18000
7. Y Rotary Axis 
1. Y as Rotary Axis*
NO
2. Rotary Y Pulse
0.006 deg/pulse
3. MM as Unit
NO
4. Rev Work Radius
0.394
5. Rotary Takeoff
Settings (continued)
