HD Series Manual
NK105G2
HD Mini Tabletop Settings
Website:support.technocnc.com | Call: 631-648-7481
Page | 4
2. Tool Change Tip*
YES
3. Cycle Times*
1
4. Deep Hole Mode*
0
5. Retract Amount*
0.039 in
6. Select Tool No*
YES
14. PLT Params 
1. Lifting Height = 0.197
2. PLT Unit = 40.000
3. Tool Stop = 0.001
4. Process Depth = -0.039
15. Tool Change 
1. ATC Capacity*
10
2. Current Tool No
1
3. Tool Offset
1. Tool 1
X: _____
Y: _____
Z: _____ (settings repeat through tool 10)
4. Tool Change Tip
NO
5. Cali Coor
1. X: Cali Coor = 0.000
Y: Cali Coor = 0.000
Z: Cali Coor = -0.039
16. Process End Tip = NO
17. Cali Tool Height = 0.250
18. ENG Unit
YES
5. MFR Param PASSWORD: 33587550
1. Velocity 
1. Decel Dist
0.394 inch
2. Approach Speed
25.00 in/min
3. Single Axis Acc
25.00 in/sec^2
4. Max Turn Acc
