HD Series Manual
NK105G2
HD Mini Tabletop Settings
Website:support.technocnc.com | Call: 631-648-7481
Page | 5
100.00 in/sec^2
5. Jerk
300.00 in/sec^3
6. Max Speed of Z
125.00 in/min
X/Y = 393.701
7. Short Seg Spd Lmt
YES
8. SPDLMT Length
0.1 inch
9. Z down option = 0
10. Z Plunge Cut Spd
11.811 in/min
11. REF Circle Radius
0.1 inch
12. REF Circle Speed
20.000 in/min
13. Jump Speed
0.000 in/min
14. Look ahead Dis
0.000 in/min
2. Axis Output Dir *
X: Negative
Y: Negative
Z: Negative
3. Pulse Equiv *
X: 0.0062500 (Tabletop)
Y: 0.0062500 (Tabletop)
Z: 0.0031250 (Tabletop)
4. Machine Stroke 
1. Strk Upper Lmt 
X: 23.750
Y: 39.500
Z: 0.000
2. Strk Lower Lmt 
X: 0.000
Y: 0.000
Z: -3.937
5. Change Tool St 
1. Strk Upper Lmt 
X: 15.748
Y: 15.748
Z: 0.000
