7
Model NVR-ELT-4 NVR-ELT-4-POE4
Dimension
205mm×206.75mm×45.2mm
Weight
0.5kg～1kg (Exclude HDD)
Installation
Mode
Desk installation
NVR-ELT-16
Model NVR-ELT-16
System
System
Resources
16-ch series product support 16 HD connection respectively. Total
bandwidth supports 28/56/80Mbps respectively.
OS
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video Decode
Type
H.264/MJPEG/MJPEG4
Decode
Capability
Max 2-ch 5M 25fps or 4-ch 3M 25fps or 4-ch 1080P 30fps
or 8-ch 720P 30fs
Video Video Input
16-ch network compression video input
Video Output
1-channel VGA analog video output
HDMI
1-ch HDMI output. Version number is 1.4
Window Split
1/4/8/9/16-window
Audio Audio Input
1-ch bidirectional talk input
Audio Output
1-ch bidirectional talk output
Audio
Compression
Standard
G.711a
Alarm Alarm Input
N/A
Alarm Output
N/A
Funciton Storage
1 built-in SATA port
Multiple-Chann
el Playback
Max 4-channel 1080P playback
Port and
Indicator
RS232 Port
N/A
RS485 Port
N/A
