4.2.4.2 Users
Go to“Main Menu”→“System”→“Users”to enter into the User interface shown as Picture
4-34.
Picture4-34
Picture4-35
Picture4-36
4.2.4.3 Info
4.2.4.3.1Info
Go to“Main Menu”→“System”→“Info”to enter into the interface shown as Picture 4-37.
User Name consists of 8 characters
and password is composed by number 0-9
with max length of 8 numbers
User can view system information, including
Device ID, Device Name, Device Type, Hardware
Version, Firmware Version, IE Client Version, IP
Address/Domain, MAC Address, HDD Capacity,
Video Format, Media Port, Web Port, etc.
Set user password. Administer is authorized to
set user common user’s authority.
Log Search: allow you check all the system
logs.
Parameter: allow you set all the parameters.
Maintain: allow you update version, recover
ex-factory value, device reboot and shut down.
Disk Management: allow you manage and
control the HDD and USB drive.
Remote Login: allow you remotely login NVR.
SEQ Control: allow you sequence live
screens for all the channels.
Manual Record: allow you manually start/stop
record.
Backup: Tick-select the ENABLE option and
select channel for backup, the user is allowed
to backup the record in the selected channel.
Live: Tick-select the ENABLE option and
select a channel and the user is allowed to
view all the live images in the selected
channel.
Playback: Tick-select the ENABLE option and
the user is allowed to playback the selected
record in the channel.
It supports up to seven users,
including one administrator and six users.
Click [Edit] button to enter into the [User
Edit] interface to input user name and
password, as shown in Picture 4-35.
Picture 4-37
