S.p.A. ITEM TE550 Instruction manual
CONTROL MODE* CURR
CURR. MIN 0.5 - 90.0 kA
CURR. MAX 0.5 - 90.0 kA
CONTROL MODE * DEG
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
CONTROL MODE * ALL
CURR. MIN 0.5 - 90.0 kA
CURR. MAX 0.5 - 90.0 kA
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
PROGRAM DATA
>PROGRAMME N. 001
WORKING MODE IK
CONTROL MODE DEG
PARAMETER VALUE RANGE
PROGRAM N. 001 – 250
WORKING MODE IK
CONTROL MODE* NO
SQUEEZE 1 00.5 - 99.5 cycles
SQUEEZE 00.5 - 99.5 cycles
PRESSURE 00,5 - 10,0 bar
FORGE DELAY 00 - 99 cycles
FORG.PRESS. 00,5 - 10,0 bar
PRE-WELD 00.0 - 99.5 cycles
PRE-POWER 05 - 99 %
COLD 1 00 - 50 cycles
SLOPE UP 00 - 25 cycles
WELD 00.5 - 99.5 cycles
CURRENT 00.5 - 90.0 kA
IMPULSE N. 01 – 50
COLD 2 00 – 50 cycles
SLOPE DOWN 00 – 25 cycles
COLD 3 00 – 50 cycles
POST-WELD 00.0 – 99.5 cycles
POST-POWER 05 – 99 %
HOLD TIME 00.5 - 99.5 cycles
OFF TIME 00.0 - 99.5 cycles
CONTROL MODE* CURR
CURR. MIN 0.5 - 90.0 kA
CURR. MAX 0.5 - 90.0 kA
CONTROL MODE* DEG
ANGLE MIN 005°-180°
ANGLE MAX 005°-180°
