2.15 – CHECK INPUT – DIAGNOSTIC TE700
-TE700 VER. 1.13--
FEATURES INVERTER
PROGRAM COPY
>DIAGNOSTIC TE700
This menu displays the status of the inputs of the TE700 weld control unit. It is used to check
the working efficiency of the external devices, connected to the TE700 control unit, required
for using the welder.
DIAGNOSTIC TE700
>START 1 PRG OFF
START1 NC-RIC7 OFF
AUX OFF
The following inputs are mentioned in the list which may be scrolled by means of the and
keys.
PARAMETER PARAMETER DESCRIPTION VALUE
START 1 PRG It indicates the status of the cycle start signal ON – OFF
START1 NC-RIC7 It indicates the status of cycle start NC signal or RIC7 ON – OFF
AUX It indicates the status of the auxiliary signal ON – OFF
AUX 3 It indicates the status of the auxiliary 3 signal ON – OFF
DOUBLE STROKE It indicates the status of the double stroke signal ON – OFF
START 2 PRG It indicates the status of the cycle 2 start signal ON – OFF
START2 NC-RIC8 It indicates the status of cycle start NC signal or RIC8 ON – OFF
TERM/FLUX It indicates the status of the thermostat signal ON – OFF
PRG.RECALL 1 It indicates the status of the recall 1 signal ON – OFF
PRG.RECALL 2 It indicates the status of the recall 2 signal ON – OFF
PRG.RECALL 3 It indicates the status of the recall 3 signal ON – OFF
PRG.RECALL 4 It indicates the status of the recall 4 signal ON – OFF
INVERTER READY It indicates the status of the READY signal from the inverter unit ON – OFF
SAFETY START 1 It indicates the status of the signal of safety start 1 ON – OFF
BIC1 NC-RIC5 It indicates the status of the NC signal of two-hand control button 1 or
RIC5
ON – OFF
SAFETY START 2 It indicates the status of the signal of safety start 2 ON – OFF
BIC2 NC-RIC6 It indicates the status of the NC signal of two-hand control button 2 or
RIC6
ON – OFF
(When Code 50200 option is present)
RESET DRESS It indicates the status of the accomplished electrodes dressing signal ON – OFF
WELD / NO WELD It indicates the status of the external weld / no weld signal ON – OFF
RESET ERROR It indicates the status of the errors clear signal ON – OFF
RESET ELECTRODE It indicates the status of the accomplished electrodes change signal ON – OFF
The input status is represented as enabled (closed input with COM1) by means of the wording
ON, while it is represented as disabled by means of the wording OFF.
