2.9 - SETUP MENU
-TE700 VER. 1.13--
PROGRAM DATA
>SETUP MENU
STEPPER MENU
In this menu, the operator may find those parameters that allow simplifying the programming
and better adjusting the control unit to the operator’s requirements.
SETUP MENU
>START 1 PRG 010
CYCLE START 2 006
PRINTER SPOTS NONE
SETUP MENU PARAMETERS TABLE
PARAMETER PARAMETER DESCRIPTION VALUE
START 1 PRG Start cycle 1 program 000 – 300
START 2 PRG Start cycle 2 program 001 – 300
PRINTER SPOTS Welding spots print ALL – NONE – BAD
STOP BAD SPOT T1 Number of spots to stop out of limit for tool 1 0 – 15
STOP BAD SPOT T2 Number of spots to stop out of limit for tool 2 0 – 15
STOP BAD SPOT T3 Number of spots to stop out of limit for tool 3 0 – 15
STOP BAD SPOT T4 Number of spots to stop out of limit for tool 4 0 – 15
LANGUAGE Language for describing parameters ITA – ENG – SPA – DEU -
FRA - UNG – POR - SWE
PRE-WELD It activates the parameters relevant to the PRE-
WELD.
ON - OFF
POST-WELD It activates the parameters relevant to the POST-
WELD.
ON - OFF
WELD 2 Activates the WELD 2 parameters ON – OFF
PROG. SEQUENCE Activates the sequence of programs ON - OFF
DYNAMIC TIME Max welding time adjustment in DYNAMIC mode 2X – 9X
DYNAMIC COMP Dynamic correction algorithm intervention
adjustment
30 % - 200 %
WELD QUALITY Activation of the quality control limits in the weld
program during the welding operation.
OFF – R ONLY – T ONLY –
R+T
START 1 PRG
This parameter indicates the program number to be run when the cycle is activated from the
start cycle 1 command.
The value of the program also includes 0 which, if set, allows the control unit to work with the
program selected in the programming frame.
START 2 PRG
This parameter indicates the program number to be run when the cycle is activated from the
start cycle 2 command.
PRINTER SPOTS
With this parameter, if the serial port is setup for print (see FEATURES TE700), the operator
can choose which welding spots to be printed. It is possible to disable the print, print all spots
or only the spots whose current value remains out of the set limits values.
