TABLE WITH SEAM WELD OPERATING MODE PARAMETERS – SECONDARY
ADJUSTMENT
PROGRAM DATA T1
>TOOLS N° 1
WORKING MODE IK
CONTROL MODE NO
PARAMETER RANGE VALUE
PROGRAM N. 001 – 300
WORKING MODE IK
CONTROL MODE * NO
SQUEEZE 1 0.5 – 99.0 cycles
SQUEEZE 00.0 – 99.0 cycles
PRESSURE 00.5 – 10.0 bar
MOTOR DELAY 05 - 99 cycles
PRE-WELD 0000 – 1000 mS
PRE CURR. 000.30 – 200.00 KA
COLD 1 0000 – 1000 mS
SLOPE UP 0000 – 1000 mS
WELD 0001 – 2000 mS
CURRENT 000.30 – 200.00 KA
COLD 2 0000 – 1000 mS
CURRENT 2 000.30 – 200.00 KA
HOLD TIME 00.5 – 99.0 cycles
CONTROL MODE * CUR
LIM I MIN 000.30 – 200.00 KA
LIM I MAX 000.30 – 200.00 KA
CONTROL MODE * RO
LIM RO MIN 005.0 – 100.0%
LIM RO MAX 005.0 – 100.0%
CONTROL MODE * VE
LIM V MIN 00.20 – 20.00 V
LIM V MAX 00.20 – 20.00 V
CONTROL MODE * PW
LIM P MIN 000.20 - 600.00 KW
LIM P MAX 000.20 – 600.00 KW
