P2002 Sierra
SECTION B
MAINTEN ANC E MAN UAL
pag.
B-14
2
st
Edition, April 22
th
, 2008
INSPECTION & SERVICING
11 LUBRICATION
11.1 INTRODUCTION
Periodic lubrication of moving parts insures proper operation and ex-
tends parts’ life considerably.
Lubrication type, points and intervals are indicated below.
Avoid excessive lubrication as this may cause external surfaces of
hinges and bearing to collect dirt and dust.
If part is not lubricated using a grease gun, grease part by hand re-
moving excess.
To grease main gear wheel bearings, first remove thrust bearings
from wheel hubs, then clean surface using solvent, apply grease and re-
assemble.
NOTE - Use grease type MIL-G-3278 or equivalent (e.g. ESSO
BEACON 325).
11.2 LUBRICATION POINTS (SEE FIG. B-7 & B-8)
1-2 Rudder hinges
3-4 Rudder control cable terminals
5 Stabilator control rod terminals
6-7 Stabilator support bearings
8-9 Trim-tab hinges
10 Tab control push-rod terminals
11 Stabilator pass-through rod
12 Stabilator control rod (inside cabin)
13-14 Aileron hinges
15 Differential ailerons hinges
16 Aileron control pushrods
17 Aileron control rods pass-trough
18 Flaps control pushrods
19-20 Flaps torque-tube support
21 Flap actuator terminals
22-23 Rudder pedals support
24-25 Rudder pushrods and cable terminals
26-27 Brake lever support
28-29 Control stick lever and support
30-31 Aileron control pulleys
32 Nose gear fork attachment hinge
33 Shock absorber attachment hinge
34 Nose gear strut attachment hinge
35 Steering pushrod terminals
Grease canopy’s ball bearings and adjustable seat rails when necessary.
