Tecnam P2002 Sierra - Primary Dimensions

2
st
Edition, April 22
th
, 2008
P2002 Sierra
MAINTEN ANC E MAN UAL
SECTION A
GENERAL
pag. A-3
PRIMARY DIMENSIONS
WING
Wing span 8.6 m
Wing surface 11.5 m
2
Wing loading 39 kg/m
2
Aspect ratio 6.4
Taper ratio 0.6
Dihedral 5°
FUSELAGE
Length overall 6.61 m
Width overall 1.11 m
Height overall 2.43 m
EMPENNAGE
Stabilator span 2.90 m
Vertical tail span 1.10 m
LANDING GEAR
Wheel track 1.85 m
Wheel base 1.62 m
Main wheel tyres: Air Trac 5.00-5
Nose gear tyre: Sava 4.00-6
CONTROL SURFACE TRAVEL RANGE
Ailerons
up 25° down 19 ° ± 2°
Stabilator
up 15° down 3° ± 1°
Trim
2° ; 9° ± 1°
Rudder
Lh 30° Rh 30° ± 2°
Flap
0°; 40° ± 1°
