INSPECTION & SERVICING
12 INSPECTION
Inspection points that are not in plain view may be accessed through spe-
cific portholes and/or removal of panels or fairings as detailed below:
1 - Portholes on wing underside - access to aileron differential bellcrank,
main spar and torque box; inspection of the wing tank outlet.
2
- Tailcone underside portholes - access to: stabilator control rod pass-
through; front attachment of vertical stabilizer; inspection of aft struc-
ture and of cables for rudder control.
3 - Tailcone end-fairing - access to stabilator torque tube and attachments
to control lever; -attachment of vertical stabilizer aft spar; -rudder
bellcrank; -trim actuator and pushrods.
4 - Aft cabin bulkhead and baggage compartment floor - inspection of
aft fuselage section and attachments; -inspection of stabilator control
system and of cable pulleys for rudder control; - access to flap actua-
tor; Remove the seats to get the access to the aileron control cable
turnbuckles.
5 - Forward cabin central fairing - access to the fuel valves and to the
rudder control cables and turnbuckles.
6 - Instrument panel cover - access to instrumentation and radio.
7 - Engine cowling
- access to engine and related systems; - access to main
components of electrical system - access to nose gear strut and steer-
ing assembly mechanism.
8 - Propeller spinner - access to propeller hub.
