SECTION F
ELECTRICAL
SYSTEM
pag.
F-5
D) First connect positive cable and then the negative to battery terminals and
apply protective grease to terminals;
E) Close the engine’s cowling
3 - GENERATOR
The generator is a permanent magnet type and supplies alternate current to a
regulator/rectifier. Servicing or repair of the generator must be carried out
only by authorized personnel.
4 - REGULATOR/RECTIFIER
A regulator/rectifier type DUCATI 965 345 is installed on the firewall with-
in the engine compartment:
To remove it proceed as follows:
A) “Master” switch OFF;
B) Disconnect wires from terminals of component to be removed;
C) Unscrew and release component;
To install it, acts as follows:
A) Secure component in place with supplied screws;
B) Connect wires to terminals.
