6.4. NLG WHEEL REMOVAL (SEE FIG.C-18)
To remove the nose gear fairings proceed as follows:
A.
To remove front portions of the fairing (5 & 6) loosening the screws (2) and
(3)
B.
Remove the two fairings (6) and (5).
C.
To remove the rear upper fairing (4) loosen the screws (1)
D.
Unscrew nuts (7) and remove washer from wheel axle
E.
Unscrew bolt (8) in gear lever housing.
F.
Remove the rear fairing (9)
Reverse procedure to reinstall. Avoid to damage the fiberglass fairing by not
tightening screws excessively.
To remove nose wheel proceed as follows:
A.
Remove the fairings (5) (6) and (9)
B.
Loosen bolts (10), (11) and (13)
C.
Detach the two wheel forks (12) from each other.
D.
Remove wheel axle
E.
Remove the wheel (13)
