Tecnam P92 Echo Super - Aircraft Alignment; Datum

P92 Echo Super
Maintenance
Manual
15
Revision Date:
10-29-2007
Revision Number: 3.01
!
!
3.4.3 Aircraft alignment
Figure 3-2
Alignments
3.4.4 Datum
Datum Distances in mm Inches
A-B
4690
" 20
184 6”
B
!
!
!
!
!
!
!
!
SPINNER
BACK
PLATE UPPER
POINT
!
!
!
!
!
!
A
A
'
!
LAST RIVET ON THE
LOWER
SIDE OF THE REAR WING
SPAR
!
!
!
!
!
!
!
C
C
'
FIRST RIVET BETWEEN
THE
TUBULAR SPAR AND THE
OUTERMOST RIB
!
UPPER/REAR RIVET ON ALUMINIUM
SKIN.
i.e. The rivet in common between the fin's rear
spar and the upper rib.
G
!
!
!
C
C'
!
!
!
F
F
'
Main
Wheels
Axle
Line
!
!
!
!
.
A‟-B
4690 " 20
184.6”
A-C
4140 " 20
163”
A‟-C‟
4140 " 20
163”
C-G
1800 " 20
70.87”
C‟-G
1800 " 20
70.87”
F-F‟
1880 " 20
74”
