Tecnam P92 Echo Super - 6.2.1 Engine Instrumentation

P92 Echo Super
Maintenance Manual
!
!
!
6.2.1 Engine instrumentation
! Electric tachometer
! Hour meter
! Electric oil temperature indicator
The sensor is located on the oil pump tube and is marked with “TO” on the pump flange.
!
! Oil pressure gauge
Sensor is located on oil tube
! Oil temperature gauge
! Coolant / Cylinder temperature gauge
! Cylinder head temperature sensors are located on cylinders 2 or 3
! Fuel Pressure Gauge
!
!
Figure 6-6 Pressure and oil temperature sensors
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
53
Revision Date:
10-29-2007
Revision Number: 3.01
