8.1.4 Engine throttle friction
A throttle friction lock is located on the instrument panel to keep the desired throttle setting.
The following placard (23x11 upper; 21x11 lower) is positioned near the friction lock knob.
8.1.5 Cabin heat
The cabin heat control knob is located on the instrument panel central area just below the left throttle control. The cabin’s
heat control is marked with this placard (20x11mm).
8.1.6 Carburetor heat
The carburetors heat control knob is located on the instrument panel central area near the central engine’s throttle. In
correspondence of it is located the following placard (20x11mm).
8.1.7 Trim switch
The trim shunt control is located on the upper central area of the instrument panel alternatively allocating trim control to
either Rh or Lh control stick. The following placard (25x14mm) is positioned just above of it.
