P92 Echo Super
Maintenance
Manual
9
Revision Date:
10-29-2007
Revision Number: 3.01
!
!
!
!
2.2 Descriptive Data
!
2.2.1 Airframe
!
2.2.1.1 Wing
!
Wing span
8.70 m (28.54 ‟ )
Wing area
12 m
2
(129 sq ft)
Aspect ratio
6.31
Taper ratio
1.0
Wing chord
1.400 m (4.6 ‟ )
Flap span
1.970 m (6.463 ‟ )
Flap chord
0.390 m (15.35”)
Aileron span
1.505 m (4.937 ‟ )
Aileron chord
0.385 m (1.263 ‟ )
!
2.2.1.2 Fuselage
!
Overall length
6.4 m (21 ‟ )
Overall width
1.1 m (43”)
Overall height
2.5 m (8.2 ‟ )
!
2.2.1.3 Empennage
!
Stabilator span
2.900 m (9.5 ‟ )
Stabilator area
1.972 m
2
(21.2 ft
2
)
Stabilator cord
0.680 m (26”)
Vertical tail span
1.230 m (3.9 ‟ )
Vertical Stabilizer area
0.720 m
2
(2.36 sq ft)
Rudder area
0.350 m
2
(1.48 sq ft)
!
2.2.1.4 Landing Gear
!
Wheel track:
1.800 m (5.9 ‟ )
Wheel base:
1.600 m (5.2 ‟ )
Main gear tire: Air Trac
5.00-5
Wheel brakes: Marc Ingegno
199 - 102
Nose gear tire: Sava
4.00-6
