Tecnam P92 Echo Super - 4.10 Nose Wheel Removal Procedure; 4.11 Tire Inflation Pressure Specifications

P92 Echo Super
Maintenance
Manual
44
Revision Date:
10-29-2007
Revision Number: 3.01
!
!
Detach the two wheel forks (12) from each other
Remove wheel axle
Remove the wheel (13)
!
!
4.10 To remove nose wheel proceed as follows:
Remove the fairings (5) (6) and (9)
Loosen bolts (10), (11) and (13)
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Figure 4-19 Removal of nosegear
fairing
!
4.11 Tire inflation pressure
Nose tire
15 psi
1.0 bar
Main tire
23 psi
1.6 bar
