FLUXMASTER 50 INSTRUCTION MANUAL
F_05: V/F Pattern Setting = 1 ~ 6
Select F_05 = 1 - 6 to select one of the six preset V/F patterns (refer to the following tables).
Specification 50Hz System
Application General Application High Starting Torque Decreasing Torque
F_5 1 2 3
50Hz System
V/F pattern
Specification 60Hz System
Application General Application High Starting Torque Decreasing Torque
F_5 4 5 6
60Hz system
V/F pattern
F_5 B C
1/4 10% 8%
2/5 15% 10.5%
3/6 25% 7.7%
